Model:G-1064-200-L-B-T-AA-G6-T-H |
|||||
|
参数Parameter |
Unit |
Min |
Max |
Typical |
Comments |
|
材料 Material |
/ |
/ |
/ |
TeO2 |
/ |
|
波长 Wavelength |
nm |
1000 |
1100 |
1064 |
/ |
|
承受光功率 Withstand optical power |
W |
/ |
3 |
/ |
/ |
|
峰值光功率 Peak(pulse) optical power |
kw |
/ |
3 |
/ |
/ |
|
声速 Ultrasonic Velocity |
m/s |
/ |
/ |
4200 |
/ |
|
插入损耗 Insertion loss |
dB |
/ |
3 |
/ |
/ |
|
偏振消光比 PER |
dB |
18 |
/ |
/ |
/ |
|
开光消光比 ER(1st order on /off) |
dB |
50 |
/ |
/ |
/ |
|
回波损耗 Return Loss (RF ON) |
dB |
40 |
/ |
/ |
/ |
|
上升/下降沿时间 Rise-time / Fall-time |
ns |
/ |
10 |
/ |
(10% - 90%) |
|
中心频率 Center Frequency |
MHz |
/ |
/ |
200 |
|
|
移频频率 Shift Frequency |
MHz |
/ |
/ |
+200 |
Can be customized -200 |
|
驱动功率 Driving Power |
W |
/ |
2.5 |
/ |
/ |
|
电压驻波比 VSWR |
/ |
/ |
/ |
1.5:1 |
/ |
|
输入阻抗 Input Impedance |
Ω |
/ |
/ |
50 |
/ |
|
射频接头 RF Interface |
/ |
/ |
/ |
SMA |
/ |
|
光纤类型Fiber Type |
/ |
/ |
/ |
PM980 |
/ |
|
光纤长度Fiber Length |
m |
/ |
/ |
1 |
/ |
|
光纤接头 Fiber Interface |
/ |
/ |
/ |
FC/APC |
/ |
|
工作温度 Working Temperature |
℃ |
/ |
/ |
-20~60 |
/ |
|
储存温度 Storage Temperature |
℃ |
/ |
/ |
-30~70 |
/ |
